1
|
THE ELECTRO-HYDRAULIC COMPACT MECHANISM GUARANTEES HIGH OPERATION SAFETY AND PRECISELY PATIENT POSITION.
|
2
|
THE RADIOLUCENT TABLE TOP PERMITTING MAXIMUM FULL BODY USE FOR A C-ARM X-RAY UNIT.
|
3
|
THE TABLE TOP DIVIDED INTO FIVE SECTIONS WITH DETACHABLE COMPLETE MATTRESS TO PROVIDE HIGH PERFORMANCE
FLEXIBLE, THE HEAD AND LEG SECTIONS CAN BE REMOVEABLE.
|
4
|
THE REMOTE CONTROL WITH COILED CABLE DRIVE FOR TABLE HEIGHT, LATERAL TILT, BACK AND PELVIS SECTIONS
ADJUSTMENT.
|
5
|
IN TOUCHING SINGLE SOFT KEY TO AUTOMATIC RETURN TABLE TOP TO ?0? HORIZONTAL POSITION
|
6
|
THE MANEUVERABILITY AND STABILITY TABLE BASE WITH MOVEABLE CASTORS WHICH CAN BE ROLLED BOTH LONGITUDINALLY
AND LATERAL. AN ELECTRO-HYDRAULIC FLOOR LOCKING DEVICE CONTROL BY REMOTE CONTROLER.
|
7
|
EQUIPPED WITH OPTIONAL UPS BATTERY BOX SUPPLY THE ENERGY UP TO 100 OPERATIONS.
|
8
|
INTEGRATED INTO THE TABLE BASE IS ELECTRO-HYDRAULIC SYSTEM, THE CONTROL SYSTEM IS SPECIAL-DESIGN AN OVERLOAD
PROTECTION DEVICE WHICH PREVENT THE EQUIPMENT DAMAGE BY ABNORMAL MOTOR PUMP OVERLOAD.
|
9
|
MOST OF THE TABLE AND ACCESSORIES ARE CONSTRUCTED BY STAINLESS STEEL.
|
